F58R38減速機詳細信息

prevnext

F58R38減速機

訂購熱線：13360667204

詳細信息

F58R38減速機電機功率：F58R38Y0.12KW減速機,F58R38Y0.18KW減速機,F58R38Y0.25KW減速機,F58R38Y0.37KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。

F58R38減速機配0.12KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F58R38-Y0.12KW	851	0.12KW	1.60r/min	610N.m	48kg	9100N	1.00
F58R38-Y0.12KW	738	0.12KW	1.90r/min	520N.m	48kg	9750N	1.15
F58R38-Y0.12KW	646	0.12KW	2.10r/min	455N.m	48kg	10200N	1.30
F58R38-Y0.12KW	558	0.12KW	2.50r/min	385N.m	48kg	10600N	1.55
F58R38-Y0.12KW	506	0.12KW	2.70r/min	345N.m	48kg	10900N	1.75
F58R38-Y0.12KW	452	0.12KW	3.00r/min	295N.m	48kg	11100N	2.00
F58R38-Y0.12KW	426	0.12KW	3.20r/min	310N.m	48kg	11100N	1.95
F58R38-Y0.12KW	382	0.12KW	3.60r/min	270N.m	48kg	11300N	2.20
F58R38-Y0.12KW	330	0.12KW	4.20r/min	230N.m	48kg	11500N	2.60
F58R38-Y0.12KW	298	0.12KW	4.60r/min	210N.m	48kg	11500N	2.80
F58R38-Y0.12KW	262	0.12KW	5.30r/min	185N.m	48kg	11500N	3.20

F58R38減速機配0.18KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F58R38-Y0.18KW	558	0.18KW	2.40r/min	635N.m	48.5kg	7570N	0.95
F58R38-Y0.18KW	506	0.18KW	2.60r/min	570N.m	48.5kg	9420N	1.05
F58R38-Y0.18KW	452	0.18KW	2.90r/min	495N.m	48.5kg	9930N	1.20
F58R38-Y0.18KW	386	0.18KW	3.40r/min	425N.m	48.5kg	10400N	1.40
F58R38-Y0.18KW	338	0.18KW	3.90r/min	370N.m	48.5kg	10700N	1.60
F58R38-Y0.18KW	426	0.18KW	3.10r/min	500N.m	48.5kg	9910N	1.20
F58R38-Y0.18KW	382	0.18KW	3.50r/min	445N.m	48.5kg	10300N	1.35
F58R38-Y0.18KW	330	0.18KW	4.00r/min	380N.m	48.5kg	10700N	1.55
F58R38-Y0.18KW	298	0.18KW	4.40r/min	340N.m	48.5kg	10900N	1.75
F58R38-Y0.18KW	262	0.18KW	5.00r/min	300N.m	48.5kg	11100N	2.00
F58R38-Y0.18KW	226	0.18KW	5.80r/min	255N.m	48.5kg	11400N	2.30
F58R38-Y0.18KW	200	0.18KW	6.60r/min	220N.m	48.5kg	11500N	2.70

F58R38減速機配0.25KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F58R38-Y0.25KW	386	0.25KW	3.40r/min	620N.m	52.5kg	8830N	0.95
F58R38-Y0.25KW	338	0.25KW	3.80r/min	540N.m	52.5kg	9640N	1.10
F58R38-Y0.25KW	255	0.25KW	5.10r/min	405N.m	52.5kg	10500N	1.45
F58R38-Y0.25KW	382	0.25KW	3.40r/min	635N.m	52.5kg	7390N	0.95
F58R38-Y0.25KW	330	0.25KW	3.90r/min	550N.m	52.5kg	9570N	1.10
F58R38-Y0.25KW	298	0.25KW	4.40r/min	495N.m	52.5kg	9950N	1.20
F58R38-Y0.25KW	262	0.25KW	5.00r/min	435N.m	52.5kg	10300N	1.35
F58R38-Y0.25KW	226	0.25KW	5.80r/min	370N.m	52.5kg	10700N	1.60
F58R38-Y0.25KW	200	0.25KW	6.50r/min	320N.m	52.5kg	11000N	1.85
F58R38-Y0.25KW	170	0.25KW	7.60r/min	275N.m	52.5kg	11300N	2.20

F58R38減速機配0.37KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F58R38-Y0.37KW	255	0.37KW	5.40r/min	580N.m	53kg	9330N	1.05
F58R38-Y0.37KW	201	0.37KW	6.90r/min	455N.m	53kg	10200N	1.30
F58R38-Y0.37KW	181	0.37KW	7.60r/min	410N.m	53kg	10500N	1.45
F58R38-Y0.37KW	262	0.37KW	5.30r/min	615N.m	53kg	9070N	0.95
F58R38-Y0.37KW	226	0.37KW	6.10r/min	525N.m	53kg	9740N	1.15
F58R38-Y0.37KW	200	0.37KW	6.90r/min	460N.m	53kg	10200N	1.30
F58R38-Y0.37KW	170	0.37KW	8.10r/min	390N.m	53kg	10600N	1.50
F58R38-Y0.37KW	152	0.37KW	9.00r/min	345N.m	53kg	10900N	1.70
F58R38-Y0.37KW	134	0.37KW	10.0r/min	305N.m	53kg	11100N	1.95

F58R38減速器減速比：134比齒輪減速馬達,152比減速器,170比減速器,181比減速器,200比減速器,201比減速器,226比減速器,255比減速器,262比減速器,298比減速器,330比減速器,338比減速器,382比減速器,386比減速器,426比減速器,452比減速器,506比減速器,558比減速器,646比減速器,738比減速器,851比減速器。

F58R38減速機電機安裝尺寸：輸出軸Φ35+鍵3（可定做），高315*寬200*長400（帶輸出軸）

F58R38減速電機輸出轉數：1.6轉減速電機,1.9轉減速電機,2.1轉平行軸斜齒輪減速機,2.4轉減速電機,2.5轉減速電機,2.6轉減速電機,2.7轉減速電機,2.9轉減速電機,3轉減速電機,3.1轉減速電機,3.2轉減速電機,3.4轉減速電機,3.5轉減速電機,3.6轉減速電機,3.8轉減速電機,3.9轉減速電機,4轉減速電機,4.2轉減速電機,4.4轉減速電機,4.6轉減速電機,5轉減速電機,5.1轉減速電機,5.3轉減速電機,5.4轉減速電機,5.8轉減速電機,6.1轉減速電機,6.5轉減速電機,6.6轉減速電機,6.9轉減速電機,7.6轉減速電機,8.1轉減速電機,9轉減速電機,10轉減速電機。

F58R38減速箱電機輸出扭矩：185N.m減速箱,210N.m減速箱,220N.m減速箱,230N.m減速箱,255N.m減速箱,270N.m減速箱,275N.m減速箱,295N.m減速箱,300N.m減速箱,305N.m減速箱,310N.m減速箱,320N.m減速箱,340N.m減速箱,345N.m減速箱,370N.m減速箱,380N.m減速箱,385N.m減速箱,390N.m減速箱,405N.m減速箱,410N.m減速箱,425N.m減速箱,435N.m減速箱,445N.m減速箱,455N.m減速箱,460N.m減速箱,495N.m減速箱,500N.m減速箱,520N.m減速箱,525N.m減速箱,540N.m減速箱,550N.m減速箱,570N.m減速箱,580N.m減速箱,610N.m減速箱,615N.m減速箱,620N.m減速箱,635N.m減速箱。

F58R38減速機電機各種輸出實物圖：

F58R38減速馬達型號：

FHZ57R37DM63L4,FHZ57R37DM63M4,FHZ57R37DM63MS4,FHZ57R37DM63S4,FHZ57R37DM71D4,FHZ57R37DM71M4,FHZ57R37DM71MS4,FHZ57R37DM71S4,FHZ57R37DR63L4,FHZ57R37DR63M4,FHZ57R37DR63MS4,FHZ57R37DR63S4,FHZ57R37DR71D4,FHZ57R37DR71M4,FHZ57R37DR71MS4,FHZ57R37DR71S4,FHZ57R37DRE63L4,FHZ57R37DRE63M4,FHZ57R37DRE63MS4,FHZ57R37DRE63S4,FHZ57R37DRE71D4,FHZ57R37DRE71M4,FHZ57R37DRE71MS4,FHZ57R37DRE71S4,FHZ57R37DRN63L4,FHZ57R37DRN63M4,FHZ57R37DRN63MS4,FHZ57R37DRN63S4,FHZ57R37DRN71D4,FHZ57R37DRN71M4,FHZ57R37DRN71MS4,FHZ57R37DRN71S4,FHZ57R37DRS63L4,FHZ57R37DRS63M4,FHZ57R37DRS63MS4,FHZ57R37DRS63S4,FHZ57R37DRS71D4,FHZ57R37DRS71M4,FHZ57R37DRS71MS4,FHZ57R37DRS71S4,FHZ57R37DT63L4,FHZ57R37DT63M4,FHZ57R37DT63MS4,FHZ57R37DT63S4,FHZ57R37DT71D4,FHZ57R37DT71M4,FHZ57R37DT71MS4,FHZ57R37DT71S4,FHZ57R37DV63L4,FHZ57R37DV63M4,FHZ57R37DV63MS4,FHZ57R37DV63S4,FHZ57R37DV71D4,FHZ57R37DV71M4,FHZ57R37DV71MS4,FHZ57R37DV71S4,FHZ57R37DVE63L4,FHZ57R37DVE63M4,FHZ57R37DVE63MS4,FHZ57R37DVE63S4,FHZ57R37DVE71D4,FHZ57R37DVE71M4,FHZ57R37DVE71MS4,FHZ57R37DVE71S4,FHZ57RF37-Y0.12KW,FHZ57RF37-Y0.18KW,FHZ57RF37-Y0.25KW,FHZ57RF37-Y0.37KW,FHZ57RF37-YEJ0.12KW,FHZ57RF37-YEJ0.18KW,FHZ57RF37-YEJ0.25KW,FHZ57RF37-YEJ0.37KW,FHZ57RF37-YVP0.12KW,FHZ57RF37-YVP0.18KW,FHZ57RF37-YVP0.25KW,FHZ57RF37-YVP0.37KW,FHZ57RF37-YVPEJ0.12KW,FHZ57RF37-YVPEJ0.18KW,FHZ57RF37-YVPEJ0.25KW,FHZ57RF37-YVPEJ0.37KW,FHZ57RF37-Y63M4,FHZ57RF37-Y71M4,FHZ57RF37-YEJ63M4,FHZ57RF37-YEJ71M4,FHZ57RF37-YVP63M4,FHZ57RF37-YVP71M4,FHZ57RF37-YVPEJ63M4,FHZ57RF37-YVPEJ71M4,FVZ57R37DM63L4,FVZ57R37DM63M4,FVZ57R37DM63MS4,FVZ57R37DM63S4,FVZ57R37DM71D4,FVZ57R37DM71M4,FVZ57R37DM71MS4,FVZ57R37DM71S4,FVZ57R37DR63L4,FVZ57R37DR63M4,FVZ57R37DR63MS4,FVZ57R37DR63S4,FVZ57R37DR71D4,FVZ57R37DR71M4,FVZ57R37DR71MS4,FVZ57R37DR71S4,FVZ57R37DRE63L4,FVZ57R37DRE63M4,FVZ57R37DRE63MS4,FVZ57R37DRE63S4,FVZ57R37DRE71D4,FVZ57R37DRE71M4,FVZ57R37DRE71MS4,FVZ57R37DRE71S4,FVZ57R37DRN63L4,FVZ57R37DRN63M4,FVZ57R37DRN63MS4,FVZ57R37DRN63S4,FVZ57R37DRN71D4,FVZ57R37DRN71M4,FVZ57R37DRN71MS4,FVZ57R37DRN71S4,FVZ57R37DRS63L4,FVZ57R37DRS63M4,FVZ57R37DRS63MS4,FVZ57R37DRS63S4,FVZ57R37DRS71D4,FVZ57R37DRS71M4,FVZ57R37DRS71MS4,FVZ57R37DRS71S4,FVZ57R37DT63L4,FVZ57R37DT63M4,FVZ57R37DT63MS4,FVZ57R37DT63S4,FVZ57R37DT71D4,FVZ57R37DT71M4,FVZ57R37DT71MS4,FVZ57R37DT71S4,FVZ57R37DV63L4,FVZ57R37DV63M4,FVZ57R37DV63MS4,FVZ57R37DV63S4,FVZ57R37DV71D4,FVZ57R37DV71M4,FVZ57R37DV71MS4,FVZ57R37DV71S4,FVZ57R37DVE63L4,FVZ57R37DVE63M4,FVZ57R37DVE63MS4,FVZ57R37DVE63S4,FVZ57R37DVE71D4,FVZ57R37DVE71M4,FVZ57R37DVE71MS4,FVZ57R37DVE71S4,FVZ57RF37-Y0.12KW,FVZ57RF37-Y0.18KW,FVZ57RF37-Y0.25KW,FVZ57RF37-Y0.37KW,FVZ57RF37-YEJ0.12KW,FVZ57RF37-YEJ0.18KW,FVZ57RF37-YEJ0.25KW,FVZ57RF37-YEJ0.37KW,FVZ57RF37-YVP0.12KW,FVZ57RF37-YVP0.18KW,FVZ57RF37-YVP0.25KW,FVZ57RF37-YVP0.37KW,FVZ57RF37-YVPEJ0.12KW,FVZ57RF37-YVPEJ0.18KW,FVZ57RF37-YVPEJ0.25KW,FVZ57RF37-YVPEJ0.37KW,FVZ57RF37-Y63M4,FVZ57RF37-Y71M4,FVZ57RF37-YEJ63M4,FVZ57RF37-YEJ71M4,FVZ57RF37-YVP63M4,FVZ57RF37-YVP71M4,FVZ57RF37-YVPEJ63M4,FVZ57RF37-YVPEJ71M4,FAZ57R37DM63L4,FAZ57R37DM63M4,FAZ57R37DM63MS4,FAZ57R37DM63S4,FAZ57R37DM71D4,FAZ57R37DM71M4,FAZ57R37DM71MS4,FAZ57R37DM71S4,FAZ57R37DR63L4,FAZ57R37DR63M4,FAZ57R37DR63MS4,FAZ57R37DR63S4,FAZ57R37DR71D4,FAZ57R37DR71M4,FAZ57R37DR71MS4,FAZ57R37DR71S4,FAZ57R37DRE63L4,FAZ57R37DRE63M4,FAZ57R37DRE63MS4,FAZ57R37DRE63S4,FAZ57R37DRE71D4,FAZ57R37DRE71M4,FAZ57R37DRE71MS4,FAZ57R37DRE71S4,FAZ57R37DRN63L4,FAZ57R37DRN63M4,FAZ57R37DRN63MS4,FAZ57R37DRN63S4,FAZ57R37DRN71D4,FAZ57R37DRN71M4,FAZ57R37DRN71MS4,FAZ57R37DRN71S4,FAZ57R37DRS63L4,FAZ57R37DRS63M4,FAZ57R37DRS63MS4,FAZ57R37DRS63S4,FAZ57R37DRS71D4,FAZ57R37DRS71M4,FAZ57R37DRS71MS4,FAZ57R37DRS71S4,FAZ57R37DT63L4,FAZ57R37DT63M4,FAZ57R37DT63MS4,FAZ57R37DT63S4,FAZ57R37DT71D4,FAZ57R37DT71M4,FAZ57R37DT71MS4,FAZ57R37DT71S4,FAZ57R37DV63L4,FAZ57R37DV63M4,FAZ57R37DV63MS4,FAZ57R37DV63S4,FAZ57R37DV71D4,FAZ57R37DV71M4,FAZ57R37DV71MS4,FAZ57R37DV71S4,FAZ57R37DVE63L4,FAZ57R37DVE63M4,FAZ57R37DVE63MS4,FAZ57R37DVE63S4,FAZ57R37DVE71D4,FAZ57R37DVE71M4,FAZ57R37DVE71MS4,FAZ57R37DVE71S4,FAZ57RF37-Y0.12KW,FAZ57RF37-Y0.18KW,FAZ57RF37-Y0.25KW,FAZ57RF37-Y0.37KW,FAZ57RF37-YEJ0.12KW,FAZ57RF37-YEJ0.18KW,FAZ57RF37-YEJ0.25KW,FAZ57RF37-YEJ0.37KW,FAZ57RF37-YVP0.12KW,FAZ57RF37-YVP0.18KW,FAZ57RF37-YVP0.25KW,FAZ57RF37-YVP0.37KW,FAZ57RF37-YVPEJ0.12KW,FAZ57RF37-YVPEJ0.18KW,FAZ57RF37-YVPEJ0.25KW,FAZ57RF37-YVPEJ0.37KW,FAZ57RF37-Y63M4,FAZ57RF37-Y71M4,FAZ57RF37-YEJ63M4,FAZ57RF37-YEJ71M4,FAZ57RF37-YVP63M4,FAZ57RF37-YVP71M4,FAZ57RF37-YVPEJ63M4,FAZ57RF37-YVPEJ71M4。
