K128R88減速機詳細信息

prevnext

K128R88減速機

訂購熱線：13360667204

詳細信息

K128R88減速機電機功率：K128R88Y1.5KW減速機,K128R88Y2.2KW減速機,K128R88Y3KW減速機,K128R88Y4KW減速機,K128R88Y5.5KW減速機,K128R88Y7.5KW減速機,K128R88Y11KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。

K128R88減速機配1.5KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
K128R88-Y1.5KW	536	1.5KW	2.70r/min	4750N.m	466kg	82400N	2.70
K128R88-Y1.5KW	418	1.5KW	3.40r/min	3740N.m	466kg	82500N	3.50
K128R88-Y1.5KW	367	1.5KW	3.90r/min	3290N.m	466kg	82600N	3.90

K128R88減速機配2.2KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
K128R88-Y2.2KW	536	2.2KW	2.70r/min	7110N.m	475kg	81700N	1.85
K128R88-Y2.2KW	473	2.2KW	3.00r/min	6220N.m	475kg	82000N	2.10
K128R88-Y2.2KW	418	2.2KW	3.40r/min	5610N.m	475kg	82200N	2.30
K128R88-Y2.2KW	367	2.2KW	3.90r/min	4910N.m	475kg	82300N	2.60
K128R88-Y2.2KW	330	2.2KW	4.30r/min	4400N.m	475kg	82400N	3.00

K128R88減速機配3KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
K128R88-Y3KW	536	3KW	2.70r/min	9580N.m	478kg	80900N	1.35
K128R88-Y3KW	473	3KW	3.10r/min	8410N.m	478kg	81300N	1.55
K128R88-Y3KW	418	3KW	3.50r/min	7560N.m	478kg	81600N	1.70
K128R88-Y3KW	367	3KW	4.00r/min	6610N.m	478kg	81900N	1.95
K128R88-Y3KW	330	3KW	4.40r/min	5930N.m	478kg	82100N	2.20
K128R88-Y3KW	287	3KW	5.10r/min	5090N.m	478kg	82300N	2.60

K128R88減速機配4KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
K128R88-Y4KW	536	4KW	2.70r/min	12800N.m	489kg	79300N	1.00
K128R88-Y4KW	473	4KW	3.10r/min	11200N.m	489kg	80100N	1.15
K128R88-Y4KW	418	4KW	3.50r/min	10100N.m	489kg	80600N	1.30
K128R88-Y4KW	367	4KW	4.00r/min	8830N.m	489kg	81200N	1.45
K128R88-Y4KW	330	4KW	4.40r/min	7930N.m	489kg	81500N	1.65
K128R88-Y4KW	287	4KW	5.10r/min	6820N.m	489kg	81800N	1.90
K128R88-Y4KW	253	4KW	5.80r/min	6030N.m	489kg	82100N	2.20

K128R88減速機配5.5KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
K128R88-Y5.5KW	418	5.5KW	3.50r/min	14000N.m	503kg	77900N	0.95
K128R88-Y5.5KW	367	5.5KW	4.00r/min	12200N.m	503kg	79600N	1.05
K128R88-Y5.5KW	330	5.5KW	4.40r/min	10900N.m	503kg	80200N	1.20
K128R88-Y5.5KW	287	5.5KW	5.10r/min	9480N.m	503kg	80900N	1.35
K128R88-Y5.5KW	253	5.5KW	5.70r/min	8380N.m	503kg	81300N	1.55
K128R88-Y5.5KW	213	5.5KW	6.80r/min	7040N.m	503kg	81800N	1.85
K128R88-Y5.5KW	200	5.5KW	7.30r/min	6710N.m	503kg	81900N	1.80
K128R88-Y5.5KW	166	5.5KW	8.80r/min	5550N.m	503kg	82200N	2.20
K128R88-Y5.5KW	147	5.5KW	9.90r/min	4900N.m	503kg	82300N	2.40

K128R88減速機配7.5KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
K128R88-Y7.5KW	330	7.5KW	4.40r/min	14800N.m	516kg	76200N	0.85
K128R88-Y7.5KW	287	7.5KW	5.10r/min	12800N.m	516kg	79300N	1.00
K128R88-Y7.5KW	253	7.5KW	5.80r/min	11300N.m	516kg	80000N	1.15
K128R88-Y7.5KW	213	7.5KW	6.90r/min	9550N.m	516kg	80900N	1.35
K128R88-Y7.5KW	200	7.5KW	7.30r/min	9100N.m	516kg	81100N	1.30
K128R88-Y7.5KW	166	7.5KW	8.80r/min	7530N.m	516kg	81600N	1.60
K128R88-Y7.5KW	147	7.5KW	10.0r/min	6640N.m	516kg	81900N	1.80

K128R88減速機配11KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
K128R88-Y11KW	213	11KW	6.90r/min	14000N.m	558kg	77900N	0.95
K128R88-Y11KW	200	11KW	7.40r/min	13300N.m	558kg	79000N	0.90
K128R88-Y11KW	166	11KW	8.90r/min	11000N.m	558kg	80200N	1.10
K128R88-Y11KW	147	11KW	10.0r/min	9760N.m	558kg	80800N	1.25

K128R88減速器減速比：147比減速器,166比齒輪減速馬達,200比減速器,213比減速器,253比減速器,287比減速器,330比減速器,367比減速器,418比減速器,473比減速器,476比減速器,536比減速器。

K128R88減速機電機安裝尺寸：輸出軸+鍵Φ116（可定做），高592*寬618（帶輸出軸）*長887

K128R88減速電機輸出轉數：2.7轉減速電機,3轉減速電機,3.1轉減速電機,3.4轉減速電機,3.5轉減速電機,3.9轉減速電機,4轉減速電機,4.3轉減速電機,4.4轉減速電機,5.1轉減速電機,5.7轉減速電機,5.8轉減速電機,6.8轉減速電機,6.9轉減速電機,7.3轉減速電機,7.4轉減速電機,8.8轉減速電機,8.9轉減速電機,9.9轉減速電機,10直角減速機。

K128R88減速箱電機輸出扭矩：3290N.m減速箱,3740N.m減速箱,4400N.m減速箱,4750N.m減速箱,4900N.m減速箱,4910N.m減速箱,5090N.m減速箱,5550N.m減速箱,5610N.m減速箱,5930N.m減速箱,6030N.m減速箱,6220N.m減速箱,6610N.m減速箱,6640N.m減速箱,6820N.m減速箱,7040N.m減速箱,7110N.m減速箱,7530N.m減速箱,7560N.m減速箱,7930N.m減速箱,8380N.m減速箱,8410N.m減速箱,8830N.m減速箱,9100N.m減速箱,9480N.m減速箱,9550N.m減速箱,9580N.m減速箱,9760N.m減速箱,10100N.m減速箱,10900N.m減速箱,11000N.m減速箱,11200N.m減速箱,11300N.m減速箱,12200N.m減速箱,12800N.m減速箱,13300N.m減速箱,14000N.m減速箱,14800N.m減速箱,67100N.m減速箱。

K128R88減速機電機各種輸出實物圖：

K128R88減速馬達型號：

KHZ127R87DM100LC4,KHZ127R87DM100LS4,KHZ127R87DM100M4,KHZ127R87DM100S4,KHZ127R87DM112M4,KHZ127R87DM132L4,KHZ127R87DM132M4,KHZ127R87DM132MC4,KHZ127R87DM132ML4,KHZ127R87DM132S4,KHZ127R87DM160L4,KHZ127R87DM160M4,KHZ127R87DM160MC4,KHZ127R87DM160S4,KHZ127R87DR100LC4,KHZ127R87DR100LS4,KHZ127R87DR100M4,KHZ127R87DR100S4,KHZ127R87DR112M4,KHZ127R87DR132L4,KHZ127R87DR132M4,KHZ127R87DR132MC4,KHZ127R87DR132ML4,KHZ127R87DR132S4,KHZ127R87DR160L4,KHZ127R87DR160M4,KHZ127R87DR160MC4,KHZ127R87DR160S4,KHZ127R87DRE100LC4,KHZ127R87DRE100LS4,KHZ127R87DRE100M4,KHZ127R87DRE100S4,KHZ127R87DRE112M4,KHZ127R87DRE132L4,KHZ127R87DRE132M4,KHZ127R87DRE132MC4,KHZ127R87DRE132ML4,KHZ127R87DRE132S4,KHZ127R87DRE160L4,KHZ127R87DRE160M4,KHZ127R87DRE160MC4,KHZ127R87DRE160S4,KHZ127R87DRN100LC4,KHZ127R87DRN100LS4,KHZ127R87DRN100M4,KHZ127R87DRN100S4,KHZ127R87DRN112M4,KHZ127R87DRN132L4,KHZ127R87DRN132M4,KHZ127R87DRN132MC4,KHZ127R87DRN132ML4,KHZ127R87DRN132S4,KHZ127R87DRN160L4,KHZ127R87DRN160M4,KHZ127R87DRN160MC4,KHZ127R87DRN160S4,KHZ127R87DRS100LC4,KHZ127R87DRS100LS4,KHZ127R87DRS100M4,KHZ127R87DRS100S4,KHZ127R87DRS112M4,KHZ127R87DRS132L4,KHZ127R87DRS132M4,KHZ127R87DRS132MC4,KHZ127R87DRS132ML4,KHZ127R87DRS132S4,KHZ127R87DRS160L4,KHZ127R87DRS160M4,KHZ127R87DRS160MC4,KHZ127R87DRS160S4,KHZ127R87DT100LC4,KHZ127R87DT100LS4,KHZ127R87DT100M4,KHZ127R87DT100S4,KHZ127R87DT112M4,KHZ127R87DT132L4,KHZ127R87DT132M4,KHZ127R87DT132MC4,KHZ127R87DT132ML4,KHZ127R87DT132S4,KHZ127R87DT160L4,KHZ127R87DT160M4,KHZ127R87DT160MC4,KHZ127R87DT160S4,KHZ127R87DV100LC4,KHZ127R87DV100LS4,KHZ127R87DV100M4,KHZ127R87DV100S4,KHZ127R87DV112M4,KHZ127R87DV132L4,KHZ127R87DV132M4,KHZ127R87DV132MC4,KHZ127R87DV132ML4,KHZ127R87DV132S4,KHZ127R87DV160L4,KHZ127R87DV160M4,KHZ127R87DV160MC4,KHZ127R87DV160S4,KHZ127R87DVE100LC4,KHZ127R87DVE100LS4,KHZ127R87DVE100M4,KHZ127R87DVE100S4,KHZ127R87DVE112M4,KHZ127R87DVE132L4,KHZ127R87DVE132M4,KHZ127R87DVE132MC4,KHZ127R87DVE132ML4,KHZ127R87DVE132S4,KHZ127R87DVE160L4,KHZ127R87DVE160M4,KHZ127R87DVE160MC4,KHZ127R87DVE160S4,KHZ127RF87-Y100M4,KHZ127RF87-Y112M4,KHZ127RF87-Y11KW,KHZ127RF87-Y11KW,KHZ127RF87-Y11KW,KHZ127RF87-Y11KW,KHZ127RF87-Y132M4,KHZ127RF87-Y15KW,KHZ127RF87-Y15KW,KHZ127RF87-Y15KW,KHZ127RF87-Y15KW,KHZ127RF87-Y160M4,KHZ127RF87-Y2.2KW,KHZ127RF87-Y2.2KW,KHZ127RF87-Y2.2KW,KHZ127RF87-Y2.2KW,KHZ127RF87-Y3KW,KHZ127RF87-Y3KW,KHZ127RF87-Y3KW,KHZ127RF87-Y3KW,KHZ127RF87-Y4KW,KHZ127RF87-Y4KW,KHZ127RF87-Y4KW,KHZ127RF87-Y4KW,KHZ127RF87-Y5.5KW,KHZ127RF87-Y5.5KW,KHZ127RF87-Y5.5KW,KHZ127RF87-Y5.5KW,KHZ127RF87-Y7.5KW,KHZ127RF87-Y7.5KW,KHZ127RF87-Y7.5KW,KHZ127RF87-Y7.5KW,KHZ127RF87-YEJ100L4,KHZ127RF87-YEJ112M4,KHZ127RF87-YEJ132M4,KHZ127RF87-YEJ160M4,KHZ127RF87-YVP100L4,KHZ127RF87-YVP112M4,KHZ127RF87-YVP132M4,KHZ127RF87-YVP160M4,KHZ127RF87-YVPEJ100L4,KHZ127RF87-YVPEJ112M4,KHZ127RF87-YVPEJ132M4,KHZ127RF87-YVPEJ160M4,KVZ127R87DM100LC4,KVZ127R87DM100LS4,KVZ127R87DM100M4,KVZ127R87DM100S4,KVZ127R87DM112M4,KVZ127R87DM132L4,KVZ127R87DM132M4,KVZ127R87DM132MC4,KVZ127R87DM132ML4,KVZ127R87DM132S4,KVZ127R87DM160L4,KVZ127R87DM160M4,KVZ127R87DM160MC4,KVZ127R87DM160S4,KVZ127R87DR100LC4,KVZ127R87DR100LS4,KVZ127R87DR100M4,KVZ127R87DR100S4,KVZ127R87DR112M4,KVZ127R87DR132L4,KVZ127R87DR132M4,KVZ127R87DR132MC4,KVZ127R87DR132ML4,KVZ127R87DR132S4,KVZ127R87DR160L4,KVZ127R87DR160M4,KVZ127R87DR160MC4,KVZ127R87DR160S4,KVZ127R87DRE100LC4,KVZ127R87DRE100LS4,KVZ127R87DRE100M4,KVZ127R87DRE100S4,KVZ127R87DRE112M4,KVZ127R87DRE132L4,KVZ127R87DRE132M4,KVZ127R87DRE132MC4,KVZ127R87DRE132ML4,KVZ127R87DRE132S4,KVZ127R87DRE160L4,KVZ127R87DRE160M4,KVZ127R87DRE160MC4,KVZ127R87DRE160S4,KVZ127R87DRN100LC4,KVZ127R87DRN100LS4,KVZ127R87DRN100M4,KVZ127R87DRN100S4,KVZ127R87DRN112M4,KVZ127R87DRN132L4,KVZ127R87DRN132M4,KVZ127R87DRN132MC4,KVZ127R87DRN132ML4,KVZ127R87DRN132S4,KVZ127R87DRN160L4,KVZ127R87DRN160M4,KVZ127R87DRN160MC4,KVZ127R87DRN160S4,KVZ127R87DRS100LC4,KVZ127R87DRS100LS4,KVZ127R87DRS100M4,KVZ127R87DRS100S4,KVZ127R87DRS112M4,KVZ127R87DRS132L4,KVZ127R87DRS132M4,KVZ127R87DRS132MC4,KVZ127R87DRS132ML4,KVZ127R87DRS132S4,KVZ127R87DRS160L4,KVZ127R87DRS160M4,KVZ127R87DRS160MC4,KVZ127R87DRS160S4,KVZ127R87DT100LC4,KVZ127R87DT100LS4,KVZ127R87DT100M4,KVZ127R87DT100S4,KVZ127R87DT112M4,KVZ127R87DT132L4,KVZ127R87DT132M4,KVZ127R87DT132MC4,KVZ127R87DT132ML4,KVZ127R87DT132S4,KVZ127R87DT160L4,KVZ127R87DT160M4,KVZ127R87DT160MC4,KVZ127R87DT160S4,KVZ127R87DV100LC4,KVZ127R87DV100LS4,KVZ127R87DV100M4,KVZ127R87DV100S4,KVZ127R87DV112M4,KVZ127R87DV132L4,KVZ127R87DV132M4,KVZ127R87DV132MC4,KVZ127R87DV132ML4,KVZ127R87DV132S4,KVZ127R87DV160L4,KVZ127R87DV160M4,KVZ127R87DV160MC4,KVZ127R87DV160S4,KVZ127R87DVE100LC4,KVZ127R87DVE100LS4,KVZ127R87DVE100M4,KVZ127R87DVE100S4,KVZ127R87DVE112M4,KVZ127R87DVE132L4,KVZ127R87DVE132M4,KVZ127R87DVE132MC4,KVZ127R87DVE132ML4,KVZ127R87DVE132S4,KVZ127R87DVE160L4,KVZ127R87DVE160M4,KVZ127R87DVE160MC4,KVZ127R87DVE160S4,KVZ127RF87-Y100M4,KVZ127RF87-Y112M4,KVZ127RF87-Y11KW,KVZ127RF87-Y11KW,KVZ127RF87-Y11KW,KVZ127RF87-Y11KW,KVZ127RF87-Y132M4,KVZ127RF87-Y15KW,KVZ127RF87-Y15KW,KVZ127RF87-Y15KW,KVZ127RF87-Y15KW,KVZ127RF87-Y160M4,KVZ127RF87-Y2.2KW,KVZ127RF87-Y2.2KW,KVZ127RF87-Y2.2KW,KVZ127RF87-Y2.2KW,KVZ127RF87-Y3KW,KVZ127RF87-Y3KW,KVZ127RF87-Y3KW,KVZ127RF87-Y3KW,KVZ127RF87-Y4KW,KVZ127RF87-Y4KW,KVZ127RF87-Y4KW,KVZ127RF87-Y4KW,KVZ127RF87-Y5.5KW,KVZ127RF87-Y5.5KW,KVZ127RF87-Y5.5KW,KVZ127RF87-Y5.5KW,KVZ127RF87-Y7.5KW,KVZ127RF87-Y7.5KW,KVZ127RF87-Y7.5KW,KVZ127RF87-Y7.5KW,KVZ127RF87-YEJ100L4,KVZ127RF87-YEJ112M4,KVZ127RF87-YEJ132M4,KVZ127RF87-YEJ160M4,KVZ127RF87-YVP100L4,KVZ127RF87-YVP112M4,KVZ127RF87-YVP132M4,KVZ127RF87-YVP160M4,KVZ127RF87-YVPEJ100L4,KVZ127RF87-YVPEJ112M4,KVZ127RF87-YVPEJ132M4,KVZ127RF87-YVPEJ160M4,KAZ127R87DM100LC4,KAZ127R87DM100LS4,KAZ127R87DM100M4,KAZ127R87DM100S4,KAZ127R87DM112M4,KAZ127R87DM132L4,KAZ127R87DM132M4,KAZ127R87DM132MC4,KAZ127R87DM132ML4,KAZ127R87DM132S4,KAZ127R87DM160L4,KAZ127R87DM160M4,KAZ127R87DM160MC4,KAZ127R87DM160S4,KAZ127R87DR100LC4,KAZ127R87DR100LS4,KAZ127R87DR100M4,KAZ127R87DR100S4,KAZ127R87DR112M4,KAZ127R87DR132L4,KAZ127R87DR132M4,KAZ127R87DR132MC4,KAZ127R87DR132ML4,KAZ127R87DR132S4,KAZ127R87DR160L4,KAZ127R87DR160M4,KAZ127R87DR160MC4,KAZ127R87DR160S4,KAZ127R87DRE100LC4,KAZ127R87DRE100LS4,KAZ127R87DRE100M4,KAZ127R87DRE100S4,KAZ127R87DRE112M4,KAZ127R87DRE132L4,KAZ127R87DRE132M4,KAZ127R87DRE132MC4,KAZ127R87DRE132ML4,KAZ127R87DRE132S4,KAZ127R87DRE160L4,KAZ127R87DRE160M4,KAZ127R87DRE160MC4,KAZ127R87DRE160S4,KAZ127R87DRN100LC4,KAZ127R87DRN100LS4,KAZ127R87DRN100M4,KAZ127R87DRN100S4,KAZ127R87DRN112M4,KAZ127R87DRN132L4,KAZ127R87DRN132M4,KAZ127R87DRN132MC4,KAZ127R87DRN132ML4,KAZ127R87DRN132S4,KAZ127R87DRN160L4,KAZ127R87DRN160M4,KAZ127R87DRN160MC4,KAZ127R87DRN160S4,KAZ127R87DRS100LC4,KAZ127R87DRS100LS4,KAZ127R87DRS100M4,KAZ127R87DRS100S4,KAZ127R87DRS112M4,KAZ127R87DRS132L4,KAZ127R87DRS132M4,KAZ127R87DRS132MC4,KAZ127R87DRS132ML4,KAZ127R87DRS132S4,KAZ127R87DRS160L4,KAZ127R87DRS160M4,KAZ127R87DRS160MC4,KAZ127R87DRS160S4,KAZ127R87DT100LC4,KAZ127R87DT100LS4,KAZ127R87DT100M4,KAZ127R87DT100S4,KAZ127R87DT112M4,KAZ127R87DT132L4,KAZ127R87DT132M4,KAZ127R87DT132MC4,KAZ127R87DT132ML4,KAZ127R87DT132S4,KAZ127R87DT160L4,KAZ127R87DT160M4,KAZ127R87DT160MC4,KAZ127R87DT160S4,KAZ127R87DV100LC4,KAZ127R87DV100LS4,KAZ127R87DV100M4,KAZ127R87DV100S4,KAZ127R87DV112M4,KAZ127R87DV132L4,KAZ127R87DV132M4,KAZ127R87DV132MC4,KAZ127R87DV132ML4,KAZ127R87DV132S4,KAZ127R87DV160L4,KAZ127R87DV160M4,KAZ127R87DV160MC4,KAZ127R87DV160S4,KAZ127R87DVE100LC4,KAZ127R87DVE100LS4,KAZ127R87DVE100M4,KAZ127R87DVE100S4,KAZ127R87DVE112M4,KAZ127R87DVE132L4,KAZ127R87DVE132M4,KAZ127R87DVE132MC4,KAZ127R87DVE132ML4,KAZ127R87DVE132S4,KAZ127R87DVE160L4,KAZ127R87DVE160M4,KAZ127R87DVE160MC4,KAZ127R87DVE160S4,KAZ127RF87-Y100M4,KAZ127RF87-Y112M4,KAZ127RF87-Y11KW,KAZ127RF87-Y11KW,KAZ127RF87-Y11KW,KAZ127RF87-Y11KW,KAZ127RF87-Y132M4,KAZ127RF87-Y15KW,KAZ127RF87-Y15KW,KAZ127RF87-Y15KW,KAZ127RF87-Y15KW,KAZ127RF87-Y160M4,KAZ127RF87-Y2.2KW,KAZ127RF87-Y2.2KW,KAZ127RF87-Y2.2KW,KAZ127RF87-Y2.2KW,KAZ127RF87-Y3KW,KAZ127RF87-Y3KW,KAZ127RF87-Y3KW,KAZ127RF87-Y3KW,KAZ127RF87-Y4KW,KAZ127RF87-Y4KW,KAZ127RF87-Y4KW,KAZ127RF87-Y4KW,KAZ127RF87-Y5.5KW,KAZ127RF87-Y5.5KW,KAZ127RF87-Y5.5KW,KAZ127RF87-Y5.5KW,KAZ127RF87-Y7.5KW,KAZ127RF87-Y7.5KW,KAZ127RF87-Y7.5KW,KAZ127RF87-Y7.5KW,KAZ127RF87-YEJ100L4,KAZ127RF87-YEJ112M4,KAZ127RF87-YEJ132M4,KAZ127RF87-YEJ160M4,KAZ127RF87-YVP100L4,KAZ127RF87-YVP112M4,KAZ127RF87-YVP132M4,KAZ127RF87-YVP160M4,KAZ127RF87-YVPEJ100L4,KAZ127RF87-YVPEJ112M4,KAZ127RF87-YVPEJ132M4,KAZ127RF87-YVPEJ160M4。
